Huawei Three-Phase Solar Inverter SUN2000-6KTL-M1 6.000W

SKU: 67554

Availability:

Out of Stock!


Huawei brings to market its line of solar inverters and it treats energy solutions with solar photovoltaic energy through its new solar inverters of the Huawei Fusion Home Sun 2000L line. The product is a powerful solar inverter because it has been invested a lot in R & D, it uses latest technology, it is compact and small and compatible with act for the connection to red. The solar inverter Huawei 6KTL-M1 is an innovative solution of Huawei for every solar installation that is connected to three-phase network with or without battery. It has a compact design and a reduced size which offer flexibility in its installation. It is very easy to control and it monitor in real time. It uses a new technology used by the SUN2000 three phase smart inverters means that provides maximum safety, not least thanks to the Arc Fault Circuit Interrupter (AFCI) which uses Artificial Intelligence (AI) technology to detect any signs of over-heating that can cause dangerous fires.

1,435.00 1,700.00 Tax inc.

Out of Stock!

X

This product is not available.
In Stock Notice

HUAWEI Three phase solar inverter SUN2000-6KTL-M1

Smart PV string inverter:

  • High efficiency inverter topology, Max. Efficiency 98.6%
  • Can be combined with Huawei Smart PV Optimizer SUN2000-450W-P, enables more modules on rooftop
  • Up to 30% higher yields contributed by optimizing each panel performance
  • Hybrid inverter with battery input
  • Integrated battery interface for future quick battery connection without extra device or retrofit cost
  • Ripple control receiver interface
  • AI-based arc detection AFCI
  • Communication:
    – Smart dongle-WLAN-FE (integrated)
    – Smart dongle-4G (optional)

Features:

  • Recommended max. PV input power: 9000 Wp
  • input voltage: 1100 V
  • Number of MPP trackers / Input number per MPP tracker: 2 / 1
  • Battery Input operating voltage range: 600 V – 980 V
  • Battery Input Max. operating current: 16 A
  • Rated output power: 6 kW
  • Rated output voltage: 220 Vac / 380 Vac, 230 Vac / 400 Vac, 3W / N+PE
  • output current: 10,1 A
  • DC and AC surge protection: Surge arresters SPD2
  • Degree of protection: IP65
  • Weight (incl. mounting bracket): 17 kg
  • Dimension (incl. mounting bracket): 525 x 470 x 146,5 mm



Video embedding powered by Webilop

Brand

HUAWEI

Weight 17 kg
Dimensions 52.5 × 47 × 14.6 cm
Power

6000 Watt
