RFID 13.56 MHz and 125KHz Handheld Copier/Writer/Reader/Duplicator (5 cards included)

Availability:

Out of Stock - Delivery in 3-4 weeks


This device is used to clone 125 KHz and 13.56 Mhz RFID cards. It can copy and duplicate the 125 Khz EM4100 / EM410X card /tag ID for backup purposes. It supports 125 KHz EM4100 / EM410X or compatible card /tag format only (HID standard is not compatible!) so that you should reference the device module when you work.  Application: It applies to access control, hotel locks, staff attendance and school campus access and payment control, identification and security systems, parking lot entry and payment, social security management, transportation, payment, municipal and ancillary service payment, etc. How to clone: 1. Push power switch on which you can find on the right of device, it will beep two or three times, and after that LED is on which mean that it works. If it is not powered on please restart. 2. Put the card near the antenna left of the device and then press READ button. The device will beep and the LED is on when it is read successful.  If it beeps 2 times go to step 3, if it beeps 3 times go to step 4, click READ again if it doesn’t beep. 3. Change a new blank card like T5557/EM4305, then press WRITE button. When it beeps and PASS LED is on it means that cloning is successful. If it doesn’t beep and light is on please write again. 4. Change a blank T5557, then press WRITE button, when it beeps and PASS LED is on it means that cloning is successful. If it doesn’t beep and light is on please write again. 5. Repeat step 3 or step 4 if you want to make more of similar ID cards. 6. Switch off so as to save power.

21.60 27.00 Tax inc.

Out of Stock - Delivery in 3-4 weeks

Specifications :

  • Brand Name: OBO HANDS
  • Model Number: NS106
  • Type: RFID NFC Copier IC/ID Reader/Writer Duplicator
  • Material: ABS
  • Card Type: Support IC/ID dual frequency replication
  • Working frequency: 125KHz, 13.56MHz
  • Support: Read and Write
  • Provide free software: Yes
  • Has a USB cabel: Yes
  • Type1: RFID Copier
  • Type2: RFID Duplicator
  • Type3: RFID Programmer
  • Type4: RFID Card reader
  • Type5: RFID Writer
  • Type6: RFID Reader Writer

Product Features :

1) Compliant with CCID

2) Compliant with PC/SC

3) Support IC/ID dual frequency replication

4) Driver-free, no need to download software installation

5) When connect the RFID Reader to the computer with the USB cable, then can find the software.

6) Support ID125K, 8800, 5200, 4305, 5577, 8265 card.

7) Support UID FUID CUID UFUID, Most of IC semi-encrypted card, IC full encryption card.

8) Has USB full speed interface

9) Two-color LED light prompt (red light is standby, green is working)

10) Built-in buzzer “beep” sound reminder

 Product Parameters:

Dimensions: 108 (L) X 68 (W) X 12 mm (H)

Interface: USB full speed

Working Voltage: 5 V DC

Working current: 200mA

Standby current: 50mA

Normal current: 100mA

Working frequency: 125KHz / 13.56 MHz

Smart card support: for 125KHz ID type: EM4100, TK4100, 8800, 5200, EM4305, T5577, 8265 etc.

For 13.56MHz IC type: UID FUID CUID UFUID, Most of IC Half-encryption, IC Full-encryption etc.

Supported operating systems: 98 Win, Win ME, Win 2000, Win XP, Win Vista, Win 7, Windows Server 2003, Windows Server 2008, Windows XP x64, Win Vista x64, Win 7×64, Win Server 2003×64, Win Server 2008×64, Win Server 2008 R2 x64, Windows CE 5.0, Windows 10

How to use the card reader?

1) Connect the device to your computer with the USB cable.

2) You can view and open the software on your computer.

Read and write ordinary 125KHz RFID card

  1. Place the card on the card reader and press “Read EMID” on the software to scan the card.
  2. The software will scan and display the card number
  3. Place a writable T5577 (125KHz writable chip) on the card reader and press “Write EMID” on the software.

Read and write 13.56MHz IC, IC half encryption card, IC full encryption card

  1. Place the card on the card reader and press ‘Read’ on the software to start decryption.
  2. “√” indicates that the decryption was successful, and “X” indicates the failure.
  3. After the decryption is successful, the software displays the card number.
  4. Place a writable UID (13.56MHz writable chip) on the card reader and press “Write Type-A” on the software.

Video embedding powered by Webilop

Weight 0.200 kg
